Program to implement the Kurskal's Algorithm to solve Minimum Cost Spanning Tree Problem (MST)

Posted By: Easy Tutor     Category: C++ Programming     Views: 8927

A C++ Program to implement the Kurskal's Algorithm to solve Minimum Cost Spanning Tree Problem (MST).

Code for Program to implement the Kurskal's Algorithm to solve Minimum Cost Spanning Tree Problem (MST) in C++ Programming

 # include <iostream.h>
 # include   <stdlib.h>
 # include    <conio.h>

 # define MAX_VERTICES  10
 # define MAX_EDGES     15

 /*************************************************************************///-------------------------------  Vertex  ------------------------------///*************************************************************************/class Vertex
 {
    public:
       int label;

    public:
       Vertex( )   {  }
       ~Vertex( )  {  }

       void SetVertex(constint);
 };

 /*************************************************************************///-------------------------------  Edge  --------------------------------///*************************************************************************/class Edge
 {
    public:
       int weight;

       Vertex V1;
       Vertex V2;

    public:
       Edge( )   { }
       ~Edge( )  { }

       void SetEdge(const Vertex,const Vertex,constint);
 };


 /*************************************************************************///----------------------------  SetVertex( )  ---------------------------///*************************************************************************/void Vertex::SetVertex(constint _label)
 {
    label=_label;
 }

 /*************************************************************************///-----------------------------  SetEdge( )  ----------------------------///*************************************************************************/void Edge::SetEdge(const Vertex _V1,const Vertex _V2,constint _weight)
 {
    V1=_V1;
    V2=_V2;

    weight=_weight;
 }

 int main( )
 {
    clrscr( );
    textmode(BW80);

    /***************************************************************            Sample Input            ************         Vertices  ,  Edges            6  ,  10           Vertex_1 , Vertex_2            320 , 100            170 , 200            320 , 250            470 , 200            220 , 400            420 , 400          Vertxe_1 ---->  Vertex_2 ,  Weight            1  ---->  2        ,  6            1  ---->  4        ,  5            1  ---->  3        ,  1            2  ---->  3        ,  5            2  ---->  5        ,  3            3  ---->  5        ,  6            3  ---->  6        ,  4            3  ---->  4        ,  5            4  ---->  5        ,  2            5  ---->  5        ,  6         Answer : 15    ***************************************************************/int vertices=0;
    int edges=0;

    cout<<"*******************  Input  ********************"<<endl;
    cout<<"Enter the Total Number of Vertices (1-10) = ";
    cin>>vertices;

    vertices=((vertices<1)?1:vertices);
    vertices=((vertices>10)?10:vertices);

    cout<<"Enter the Total Number of Edges (1-15) = ";
    cin>>edges;

    edges=((edges<0)?0:edges);
    edges=((edges>15)?15:edges);

    Vertex  V[MAX_VERTICES];
    Edge    E[MAX_EDGES];

    for(int count=0;count<vertices;count++)
       V[count].SetVertex(count);

    int v1;
    int v2;
    int weight;

    cout<<"\n **********  Edges and their Weights  ********* "<<endl;

    for(count=0;count<edges;count++)
    {
       cout<<"    ----------       ---------->";

       gotoxy(2,wherey( ));
       cin>>v1;

       gotoxy(35,(wherey( )-1));
       cin>>v2;

       gotoxy(17,(wherey( )-1));
       cin>>weight;

       v1=((v1<1)?1:v1);
       v1=((v1>vertices)?vertices:v1);

       v2=((v2<1)?1:v2);
       v2=((v2>vertices)?vertices:v2);

       weight=((weight<=0)?0:weight);

       E[count].SetEdge(V[(v1-1)],V[(v2-1)],weight);
    }

    cout<<endl<<"Press any key to Apply Kruskal's Algorithm...";

    getch( );
    clrscr( );

    cout<<"*******************  Input  ********************"<<endl;
    cout<<" V = { ";

    for(count=1;count<vertices;count++)
       cout<<count<<",";

    cout<<count<<" } "<<endl;

    cout<<" E = { ";

    for(count=0;count<edges;count++)
    {
       cout<<"("<<(E[count].V1.label+1)<<","<<(E[count].V2.label+1)<<")";

       if(count<(edges-1))
      cout<<",";
    }

    cout<<" } "<<endl<<endl;

    for(int i=0;i<edges;i++)
    {
       for(int j=0;j<(edges-1);j++)
       {
      if(E[j].weight>=E[(j+1)].weight)
      {
         Edge Temp;

         Temp=E[j];
         E[j]=E[(j+1)];
         E[(j+1)]=Temp;
      }
       }
    }

    int e_count=0;
    int cycle_flag=0;

    Edge _E[MAX_EDGES];

    int mst[MAX_VERTICES][MAX_VERTICES]={0};

    for(i=0;i<=vertices;i++)
    {
       mst[i][0]=i;

       for(int j=1;j<vertices;j++)
      mst[i][j]=-1;
    }

    for(count=0;count<edges;count++)
    {
       cycle_flag=0;

       for(i=1;i<vertices;i++)
       {
      if(mst[E[count].V1.label][i]==E[count].V2.label ||
                   mst[E[count].V2.label][i]==E[count].V1.label)
         cycle_flag=1;
       }

       if(!cycle_flag)
       {
      _E[e_count]=E[count];

      e_count++;

      for(i=1;i<vertices;i++)
      {
         if(mst[E[count].V1.label][i]==E[count].V2.label)
        break;

         if(mst[E[count].V1.label][i]==-1)
         {
        mst[E[count].V1.label][i]=E[count].V2.label;

        break;
         }
      }

      for(i=1;i<vertices;i++)
      {
         if(mst[E[count].V2.label][i]==E[count].V1.label)
        break;

         if(mst[E[count].V2.label][i]==-1)
         {
        mst[E[count].V2.label][i]=E[count].V1.label;

        break;
         }
      }

      for(i=0;i<vertices;i++)
      {
         for(int j=0;j<vertices;j++)
         {
        for(int k=1;k<vertices;k++)
        {
           if(mst[j][k]!=-1)
           {
              for(int l=1;l<vertices;l++)
              {
             if(mst[mst[j][k]][l]!=-1)
             {
                for(int m=0;m<vertices;m++)
                {
                   if(mst[mst[j][k]][l]==mst[j][m])
                  break;

                   if(mst[j][m]==-1)
                   {
                  mst[j][m]=mst[mst[j][k]][l];

                  break;
                   }
                }
             }
              }
           }
        }
         }
      }
       }
    }

    cout<<"*******************  Result  ********************"<<endl;
    cout<<" V = { ";

    for(count=1;count<vertices;count++)
       cout<<count<<",";

    cout<<count<<" }"<<endl<<" E = { ";

    for(count=0;count<(e_count-1);count++)
       cout<<"("<<(_E[count].V1.label+1)<<","<<(_E[count].V2.label+1)<<"),";

       cout<<"("<<(_E[count].V1.label+1)<<","<<(_E[count].V2.label+1)<<") }"<<endl;

    cout<<" Total Cost = ";

    int cost=0;

    for(count=0;count<e_count;count++)
    {
       cost+=_E[count].weight;

       if(count<(e_count-1))
      cout<<_E[count].weight<<"+";
    }

    cout<<_E[count-1].weight<<" =  "<<cost<<endl<<endl;
    cout<<endl<<" Press any Key to Exit...";

    getch( );
    return 0;
 }
